BMT-P2/144A(550W)P19
STANDARD INSTALLATION MANUAL FOR POLARIS 580W (HOOP INSTALLATION)
FIGURE 21
● Use tape to adhere the waterproof strip along the upper edge of the frame of the rst row
of products. Ensure that the edge of the waterproof strip is aligned with the upper edge of the
frame (Figure 22). With this, installation of the rst row of products is completed.
● Before installation of the second row of the products, install two positioning hooks on the
bottom frame of the product. (Figure 23) The distance between two positioning hooks and the
right and left frames should be 200mm (Figure 24).
FIGURE 22
● Following the installation method of the second product, install the remaining products from
right to left, until the rst row of products is installed. (Figure 21)
563mm
Waterproof strip
Top framePolaris series
