34
06 Electrical Connection
User Manual V1.2-2024-10-30
WARNING
• Pay attention to the L1, L2, L3, N and PE terminals. Connect the AC cables to the
corresponding terminals. The inverter may be damaged if the cables are connected to the
wrong terminal.
• Ensure that the whole cable cores are inserted into the terminal holes. No part of the cable
core can be exposed.
• Ensure that the cables are connected securely. Otherwise it will cause damage to the
inverter due to overheat during its operation.
• Connect the ON-GRID cable before BACK-UP cable when connecting the AC cables.
Inverter Model RCD Type (GRID) RCD Type (BACK-UP)
GW50K05-ETC
500mA
30mA
GW50K06-ETC
GW50K07-ETC
GW100K05-ETC
1000mAGW100K06-ETC
GW100K07-ETC
GW50K05-BTC
500mAGW50K06-BTC
GW50K07-BTC
GW50K05-BTC
1000mAGW100K06-BTC
GW100K07-BTC
Connect a Residual Current Device (RCD for short) based on local laws and regulations. Type A
RCDs can be connected to the outside of the inverter for protection when the DC component of
the leakage current exceeds the limit value. The following RCDs are for reference:
DANGER
• Do not connect one PV string to more than one inverter at the same time. Otherwise, it may
cause damage to the inverter.
• Conrm the following information before connecting the PV string to the inverter. Otherwise,
the inverter may be damaged permanently or even cause re and cause personal and
property losses.
1. Make sure that the max short circuit current and the max input voltage per MPPT are
within the permissible range.
2. Make sure that the positive pole of the PV string connects to MPPT+ of the inverter. And
the negative pole of the PV string connects to MPPT- of the inverter.
Safety Precautions - PV Input Cable
NOTICE
Load Output Cable only for GW50K07-ETC, GW100K07-ETC, GW50K07-BTC, GW100K07-BTC.
