10
03 Product Introduction
User Manual V1.2-2024-10-30
S1 S2
P1 P2
1
10
11
ON-GRID
BACK-UP
BACK-UP
BACK-UP
ON-GRID
ON-GRID
2
4
7
8
9
12
13
6
5
3
Smart
meter
Smart
meter
AC-Coupled Scenario
Meter
Utility
Grid
PV string
Battery
AC circuit breaker
AC-Coupled
inverter(Main)
Grid-tied PV
inverter
NOTICE
• Before enabling the power limit function, ensure that the AC-Coupled inverter or grid-tied
PV inverter supports power limit.
• Enable the power limit function if GoodWe AC-Coupled inverter or grid-tied PV inverter is
applied in the PV system. Complete the power limit settings as required if a grid-tied PV
inverter from other manufacturers is applied.
• When power limit function is enabled, the PV system will purchase 2.5kW power from the
utility grid.
AC-Coupled
inverter(slave)
(n-1)
AC-Coupled
inverter(slave)
(n) 1≤n≤3
Battery
Battery
Load
breaker
SPDT
BACK-UP loads
Load
breaker
SPDT
BACK-UP loads
