03 Product Introduction
User Manual V1.2-2024-10-30
No� Parts Description
1 PV string The PV string is composed of series connected PV panels. Only for
hybrid inverters.
2 Battery Select the battery model according to the inverter model and the
approved battery list.
3 Inverter Supports ETC series inverters.
4 SPDT (Single
Pole, Double
Throw) switch
• An SPDT switch is recommended to ensure that the BACK-
UP loads do not stop working when the inverter is o or in
maintenance..
• Recommended specications of SPDT switch:
• GW50K06-ETC, and GW50K07-ETC: the nominal current is
≥125A and the nominal voltage is ≥415V.
• FGW100K06-ETC, and GW100K07-ETC: the nominal current is
≥250A and the nominal voltage is ≥415V.
5 Load breaker Depends on the actual using load.
6 Smart meter The smart meter can be purchased from the inverter manufacturer.
Recommended model: GM3000C, GM330.
7 BACK-UP
loads
• Connecting BACK-UP loads, such as loads requiring 24-hour
power supply or other important loads.
• Connecting unbalanced loads. L1, L2, L3 of the inverter
respectively connected to loads with dierent power.
8 Power
distribution
panel
• A distribution board should be prepared by the customer.
• Nominal current of the distribution panel ≥2 x N x I
max
(N refers
the quantity of the inverters in the system; I
max
refers to the
maximum output current of the inverter.
9 Load breaker Depends on the actual using load.
