10 Technical Data
93
Derating Temperature (℃) 45
Storage Temperature (℃) -40~+70
Relative Humidity 0~100%
Max. Operating Altitude (m) 4000
Cooling Method Natural Convection
User Interface LED, LCD (Optional), WLAN+APP
Communication RS485, WiFi, LAN or 4G or Bluetooth(Optional)
Weight (Kg) 15.1 16.6
Dimension (W×H×Dmm) 491×392×210
Noise Emission (dB) <30
Topology Non-isolated
Night Power Consumption (W) <1
Ingress Protection Rating IP66
Anti-corrosion Class C4,C5(Optional)
DC Connector MC4( 4~6mm²)
AC Connector OT terminal (Max.10 mm²)
OT terminal
(Max. 16 mm²)
Environmental Category 4K4H
Pollution Degree III
Overvoltage Category DC II / AC III
Protective class I
The Decisive Voltage Class (DVC)
PV:C
AC:C
Com:A
Active Anti-islanding Method AFDPF + AQDPF
*1
Country of Manufacture China
*1: AFDPF: Active Frequency Drift with Positive Feedback, AQDPF: Active Q Drift
with Positive Feedback.
*2: For Brazil Max. Input Power (kW), GW8000-SDT-30 is 14.4, GW10K-SDT-30 is
18, GW12K-SDT-30 is 21.6, GW15K-SDT-30 is 27, GW17K-SDT-30 is 30.6, GW20K-
SDT-30 is 36.
*3: For Brazil and Chile, the Max. AC Active Power (kW) &Max. AC Apparent
Power (kVA): GW4000-SDT-30 is 4, GW5000-SDT-30 is 5, GW6000-SDT-30 is 6,
GW8000-SDT-30 is 8, GW10K-SDT-30 is 10, GW12K-SDT-30 is 12, GW15K-SDT-30
is 15.
*4: For Brazil and Chile, Max. Output Current (A) and Nominal Output Current
(A): GW8000-SDT-30 is 12.1, GW10K-SDT-30 is 15.2, GW12K-SDT-30 is 18.2,
GW15K-SDT30 is 22.7.
