10 Technical Data
92
Max. Output Fault Current (Peak
and Duration) (A)
42 ,6.5μs 67 ,6.5μs
Inrush Current (Peak and
Duration) (A)
23.7 (at 50μs)
Nominal Output Current (A)
*4
11.6 14.5 14.5 17.4
Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic Distortion <3%
Maximum output overcurrent
protection(A)
42 42 42 67
Eciency
Max. Eciency 98.5%
European Eciency 98.0% 98.2%
Protection
PV String Current Monitoring Integrated
PV Insulation Resistance
Detection
Integrated
Residual Current Monitoring Integrated
PV Reverse Polarity Protection Integrated
Anti-islanding Protection Integrated
AC Overcurrent Protection Integrated
AC Short Circuit Protection Integrated
AC Overvoltage Protection Integrated
DC Switch Integrated
DC Surge Protection Type III (Type II Optional )
AC Surge Protection Type III (Type II Optional )
AFCI Optional
Emergency Power O Optional
Rapid Shutdown Optional
Remote Shutdown Optional
PID Recovery Optional
Power Supply at Night Optional
General Data
Operating Temperature Range (℃) -30~+60
