10 Technical Data
112
Max. Output Fault Current
(Peak and Duration) (A)
73 (at 6.5μs) 73 (at 6.5μs) 95 (at 6.5μs)
Inrush Current (Peak and
Duration) (A)
30.2 (at 50μs) 30.2 (at 50μs) 29.4 (at 50μs)
Nominal Output Current (A)
*4
30.3 31.5 37.9
Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic
Distortion
<3% <3% <3%
Maximum output overcurrent
protection(A)
73 73 95
Eciency
Max. Eciency 98.5% 98.2% 98.5%
European Eciency 97.9% 97.2% 97.9%
Protection
PV String Current Monitoring Integrated Integrated Integrated
PV Insulation Resistance
Detection
Integrated Integrated Integrated
Residual Current Monitoring Integrated Integrated Integrated
PV Reverse Polarity
Protection
Integrated Integrated Integrated
Anti-islanding Protection Integrated Integrated Integrated
AC Overcurrent Protection Integrated Integrated Integrated
AC Short Circuit Protection Integrated Integrated Integrated
AC Overvoltage Protection Integrated Integrated Integrated
DC Switch Integrated Integrated Integrated
DC Surge Protection
Type III (Type II
Optional )
Type II
Type III (Type II
Optional)
AC Surge Protection
Type III (Type II
Optional)
Type III (Type II
Optional)
Type III (Type II
Optional)
AFCI Optional Optional Optional
Emergency Power O Optional Optional Optional
Rapid Shutdown Optional Optional Optional
Remote Shutdown Optional Optional Optional
PID Recovery Optional Optional Optional
Power Supply at Night Optional Optional Optional
General Data
