10 Technical Data
106
Inrush Current (Peak and
Duration) (A)
60 (at 500μs) 60 (at 500μs) 60 (at 500μs)
Nominal Output Current (A)
50.1 @380Vac
47.9 @400Vac
45.9 @415Vac
54.6 @380Vac
52.3 @400Vac
50.1 @415Vac
60.7 @380Vac
58.0 @400Vac
55.6 @415Vac
Power Factor
~1 (Adjustable from
0.8 leading to 0.8
lagging)
~1 (Adjustable from
0.8 leading to 0.8
lagging)
~1 (Adjustable
from 0.8 leading to
0.8 lagging)
Max. Total Harmonic Distortion <3% <3% <3%
Maximum output overcurrent
protection(A)
126 157 157
Eciency
Max. Eciency 98.6% 98.6% 98.6%
European Eciency 97.8% 97.8% 97.8%
Protection
PV String Current Monitoring Integrated Integrated Integrated
PV Insulation Resistance Detection Integrated Integrated Integrated
Residual Current Monitoring Integrated Integrated Integrated
PV Reverse Polarity Protection Integrated Integrated Integrated
Anti-islanding Protection Integrated Integrated Integrated
AC Overcurrent Protection Integrated Integrated Integrated
AC Short Circuit Protection Integrated Integrated Integrated
AC Overvoltage Protection Integrated Integrated Integrated
DC Switch Integrated Integrated Integrated
DC Surge Protection
Type III (Type II
Optional)
Type III (Type II
Optional)
Type III (Type II
Optional)
AC Surge Protection
Type III (Type II
Optional)
Type III (Type II
Optional)
Type III (Type II
Optional)
AFCI Optional Optional Optional
Emergency Power O
*3
Integrated Integrated Integrated
Rapid Shutdown Optional Optional Optional
Remote Shutdown ＮＡ ＮＡ ＮＡ
PID Recovery Optional Optional Optional
Power Supply at Night Optional Optional Optional
Operating Temperature Range (℃) -30 ~ 60 -30 ~ 60 -30 ~ 60
Derating Temperature (℃) 45 45 45
