10 Technical Data
105
Technical Data GW33K-SDT-C30 GW36K-SDT-C30 GW40K-SDT-C30
Input
Max.Input Power (W)
*2
49,500 54,000 60,000
Max.Input Voltage(V) 1,100 1,100 1,100
MPPT Operating Voltage Range (V) 140~1000 140~1000 140~1000
MPPT Voltage Range at Nominal
Power (V)
480~850 480~850 480~850
Start-up Voltage (V) 160
Nominal Input Voltage (V) 600 600 600
Max. Input Current per MPPT (A) 42/42/32
Max. Short Circuit Current per
MPPT (A)
52.5/52.5/40
Max.Backfeed Current to The
Array(A)
0 0 0
Number of MPP trackers 3 3 3
Number of Strings per MPPT 2 2 2
Output
Nominal Output Power (W) 33,000 36,000 40,000
Nominal Output Apparent Power
(VA)
33,000 36,000 40,000
Max. AC Active Power (W) 33,000 36,000 40,000
Max. AC Apparent Power (VA) 33,000 36,000 40,000
Nominal Power at 40℃(W) 33,000 36,000 40,000
Max Power at 40℃ (including AC
overload) (W)
33,000 36,000 40,000
Nominal Output Voltage (V)
220/380, 230/400,
240/415, 3L/N/PE or
3L/PE
220/380, 230/400,
240/415, 3L/N/PE
or 3L/PE
220/380, 230/400,
240/415, 3L/N/PE
or 3L/PE
Output Voltage Range (V)
180~280 (according
to local
standard)
180~280 (according
to local
standard)
180~280
(according to local
standard)
Nominal AC Grid Frequency (Hz) 50 50 50
AC Grid Frequency Range (Hz) 45~55
Max. Output Current (A) 50.1 54.6 60.7
Max. Output Fault Current (Peak
and Duration) (A)
126 (at 6.5μs) 157 (at 6.5μs) 157 (at 6.5μs)
