02 Safety PrecautionUser Manual V1.2-2025-01-13
3
2.3 AC Side
WARNING
• The voltage and frequency at the connecting point should meet the on-grid requirements.
• An additional protective device like the circuit breaker or fuse is recommended on the AC
side. Specication of the protective device should be at least 1.25 times the Max. Output
Current.
• Make sure that all the groundings are tightly connected. When there are multiple inverters,
make sure that all the grounding points on the enclosures are equipotential bonding.
• You are recommended to use copper cables as AC output cables. If you prefer aluminum
cables, remember to use copper to aluminum adapter terminals.
WARNING
• Ensure that the PV module frames and the PV mounting system are securely grounded.
• Ensure that the DC cables are connected tightly and securely.
• The PV modules used with the inverter must have an IEC61730 class A rating.
• Make sure that the PV strings connected to the same MPPT should contain the same
number of identical PV modules.
• To maximize the power generation of the inverter, please ensure that the Vmp of the PV
modules connected in series is within the MPPT Voltage Range at Nominal Power of the
inverter, as shown in the Technical Parameters.
• Make sure that the voltage dierence between two MPPTs shall be less than 150 V.
• Make sure that the input current of each MPPT does not exceed the Max. Input Current
per MPPT, as shown in the the Technical Parameters.
• When there are multiple PV string inputs, please connect them to as much inverter MPPTs
as possible.
