06 Electrical Connection
23
User Manual V2.2-2025-07-24
6.4 Connecting the AC Output Cable
WARNING
• Do not connect loads between the inverter and the AC switch directly connected to the
inverter.
• The Residual Current Monitoring Unit (RCMU) is integrated into the inverter. The inverter
will disconnect the utility grid rapidly once it detects any leak current over the permissible
range.
An AC circuit breaker shall be installed on the AC side to make sure that the inverter can safely
disconnect the grid when an exception happens. Select the appropriate AC circuit breaker in
compliance with local laws and regulations. Recommended AC circuit breakers:
Model RCD specications
GW5000-MS-30
300mA
GW6000-MS-30
GW7000-MS-30
GW8500-MS-30
GW9900-MS-30
GW10K-MS-30
GW7000-MS-C30
GW8000-MS-C30
A type A RCD(Residual Current Device) shall be added to protect the equipment when the DC
component of the leakage current exceeds limits. Recommended RCD specications:
Inverter model AC circuit breaker
GW5000-MS-30 32A
GW6000-MS-30 40A
GW7000-MS-30 50A
GW8500-MS-30 63A
GW9900-MS-30 63A
GW10K-MS-30 63A
GW7000-MS-C30 50A
GW8000-MS-C30 50A
