2.6 Attaching the water feed hose to the tap
• Pull the sleeve down with your fingers
as you lower the entries hose to
disconnect the union.
• Loosen the four screws on the hose
union and then fit the union exactly
over the mouth of the tap.
• Tighten the four screws evenly around
the tap.
• Remove the seal from the union and
turn the nozzle to tighten securely. (If
the tap is large, square or oddly
shaped, remove the inside ring to
facilitate attachment).
• Grip the ring with your hand and pull it
down, and then insert the nozzle.
Separate the sleeve until you hear a
click, and then push it back.
• After installation, check to ensure that the union does not come off
while pulling down.
• Next, confirm that the union is properly installed by turning the water
on and checking for leakage.
• If you see any leakage adjust the section where there is a leakage.
• A secure water connection for your automatic washing machine will
help you to use the auto start feature.
10
*The images are for representation purpose only
21
5.0 MAINTENANCE
5.1 Cleaning of Water Inlet
If the water fills into the basket too slowly –
1) Stop water supply, unscrew fill hose
from the machine.
2) Gently pull out the filter.
3) Wash the filter thoroughly in running
water.
4) Fit back filter on the machine and
tighten the hose.
Note - Clean the washer inlet valve filter as and when required.
5.2 Washing Machine Body
• Before carrying out any maintenance on your washing machine,
be sure to remove the electrical plug from its power source.
• Clean the main body and control panel with a soft cloth.
• Hard-to-remove dirt can be cleaned by wiping with a soft cloth
soaked in a mild detergent.
Caution:
• Do not clean the body or control panel with benzene, thinner,
cleanser or other chemical cleaners.
• This can discolour or damage your machine’s finish.
5.3 Cleaning the Magic Filter
Clean the lint collector after every use. Follow these steps:
• Remove the lint collector by pulling it out. If it is difficult to lift it out at
the place where the machine has stopped, turn the basket by hand
to a more convenient place and remove the lint collector.
• Open the cover of the lint collector as shown.
• Clean the filter in running water.
• When the lint collector has been emptied and cleaned, close the
front cover and replace the lint collector by inserting it from the
bottom and pressing it back into place.
Filter
Water inlet
Press the lock to remove the
magic filter.
Open the cover and clean
the filter in running water.
Close the cover
and fit the magic
filter as shown.
