2.4 Installing the drain hose
• Insert the drain hose as far as it will
go inside, then secure it tightly with
the hose clamp. An improperly
secured hose may leak.
• While attaching the drain to a wash
pan, leave a gap between the end of
the hose and the adjacent surface.
• If the flat end of the hose comes in
contact with a flat surface, drain will
be affected.
Caution
• If the drain hose is not installed
properly, your washing machine may
not function well, and the overflow
prevention mechanism may cause
your machine to stop mid-cycle.
• While inserting the drain hose into a
wash pan or drain pipe, move the
hook for easier installation.
• Move the hook back to its initial
position before placing it in the slot
provided on the backside of your
machine.
• Make sure the drain hose is not too
high else it may get clogged and
give error signal.
Drain hose
Hook
3m or less
Drain hose cap
15 cm or less
Drain hole
Gap
3 cm or
greter
Cut diagonally
Drain Hose
9
2.5 Installing the Rat Mesh
Tilt the washer on the front side and slide
the Rat Mesh as shown in fig.1 and
screw it to the base as shown in the fig.2
Rat Mesh
Slide the Rat Mesh into
machine base from back side
of the the machine as shown.
Use 2 nos. screw to fit
the Rat Mesh with machine Base
as shown.
Machine Base
22
5.4 Fuzzy Calibration:
Due to aging, the mechanical friction changes on motor, belt
tension and other mechanical parts. Hence it is required to
calibrate the machine for fuzzy sensing. Calibration can be done
by pressing CYCLE + START / PAUSE + POWER button together
for 2sec and machine will automatically perform the calibration.
• Fuzzy Calibration should be started with empty tub, i.e. without
water and clothes inside the wash tub.
•
