German Light Products® Wild Bar 16
Rev. 20250228-01 9
RGB Mode: Mixes color of the main and sub module(s) using Red, Green and Blue
channels. The Lime LED is mixed automatically using the fixture’s internal GLP
iQ.Gamut algorithm.
RGBL Mode: Mixes color of the main module using Red, Green, Blue and Lime
channels.
iQ.Gamut
iQ.Gamut is a new LED calibration technology from GLP that defines the color gamut for
the color mix channels. You can select one of a range of calibrated iQ.Gamuts for the
fixture to work within. This feature can be useful if you want to reproduce correct colors
or avoid TV camera clipping. Set using the option Fixture Settings→iQ.Gamut.
White Point
The white point is the output color when all color control channels are at 100%. You can
set this to a Kelvin color temperature using the option Fixture Settings→White Point.
Tungsten effect
This control channel lets you set various tungsten lamp simulations.
The first part of the Tungsten channel offers standard tungsten features with fixed color
temperature, red shift and fade time. The color temperature as well as the color shift
and inertia of the selected light source are fully simulated.
The second part of the Tungsten channel lets you apply one of the corresponding
tungsten effects (inertia and intensity) to the current output.
Note: The Tungsten simulation channel affects the entire fixture. Setting the Tungsten
channel to a specific value will affect the output of the Main module and Sub module.
Shutter
The fixture’s shutter channel offers continuous blackout, continuous open and a range
of intensity effects.
Depending on the selected Sub Module Mode, the shutter channel of the Main module
channel group acts as either a master shutter or as the shutter channel of the Main
module independently of the Sub module.
The following shutter effects are available:
● Single flash performs exactly one single flash with each value change within this
DMX value slot.
● Pulse dims up and down smoothly with the same fade-in and fade-out times. Speed
can be adjusted from slow to fast.
● Pulse open fades in and then snaps to blackout. Speed can be adjusted from slow to
fast.
● Pulse close fades out and then snaps to full. Speed can be adjusted from slow to
fast.
● Strobe double flash provides a quick double flash. Speed can be adjusted from slow
to fast.
