German Light Products® Wild Bar 16
Rev. 20250228-01 13
4. Control panel
Warning! DMX control is disabled when the control menus are active. Be
prepared for the head to move as soon as you exit the control menus.
The control panel and backlit graphic LCD display with self-charging battery allow you
to change fixture settings, view readouts and use utilities quickly and intuitively, even
when the fixture is disconnected from power.
To allow comfortable use of the control panel, tilt is automatically disabled for a few
seconds if you press any button on the control panel. Tilt remains disabled for as long
you are working in the control panel. If no button is pressed for a few seconds, head
movement is re-enabled with tilt correction applied.
Default information screen
When power is applied, the fixture performs a reset. After the reset has completed, the
default information screen appears in the control panel display on the side of the yoke.
At any other time, you can press any key to unlock the control panel. Doing this also
calls up the default information screen in the control panel display.
See Figure 3. The top line of the default information screen consists of, from left to right:
● Main CPU firmware version
● DMX Mode
The center of the screen shows the following information:
0.2.2/M1
DMX
001
(1…27)
No link 2.0.0.1/8 (Static)
Figure 3. Default information screen
