www.glp.de Matrix Eye
10 Matrix Eye User Manual
operate on full output for a short time before the output is reduced to keep the xture
temperature below limits. When Boost Mode is set to Constant, the xture outputs at a
standard level continuously.
Color Mix Mode ( RGBAL / RGB )
The xture uses 5 colors of LED emitter – Red, Green, Blue, Amber, Lime – to produce
the output.
In DMX Modes 2-4, the Fixture Settings → Color Mix Mode setting lets you choose to
control the 5 colors independently (RGBAL mode), or to set the output color using RGB
controls and have the xture automatically set the Amber and Lime emitters for best
color mix (RGB mode). The CTC channel may be used to set the white point of the
xture when all control channels are at 100%.
In DMX Mode 5, RGB mode is always used.
White Point setting
In Color Mix RGB mode only, you can select different White Points (white balance) or
disable White Point. This is set using the Fixture Settings → White Point menu option.
If a White Point is set, it will determine the white output of the xture when all RGB
control channels are at 100%.
If White Point is set to Off, and RGB is set to 100%, all colors will run with maximum
intensity. This gives the highest output but no dened White Point.
Colormix Speed
For a smoother and more attractive color fade, the xture internally calculates a
transition between different color settings. If you need a fast snap between colors (for
example if the xture is used for video mapping), set the Fixture Settings → Colormix
Speed option to Snap. This will remove the internal fade and give instant change
between color settings.
Duration
The Flash Duration Channel sets the length of a ash from super short to long ashes.
The control can be set as Normal (xed duration) or Percentage (of ash rate) using the
Fixture Settings → Duration Control setting.
Rate (Shutter)
The operator can adjust the interval between ashes or the speed of Intensity Effects.
If the Intensity Effects Channel is set to DMX 000..004 the Rate Channel will perform as
a standard Strobe Channel and will adjust the Strobe speed as follow:
• At DMX 000..004 the xture will be in blackout (Shutter Blackout)
• At DMX 255 the xture will be continuously on (Shutter Open)
• In between the above values the xture will perform ashes with long interval to
very short interval
