German Light Products Matrix Eye
Rev. 20250711-0 15
4. Control panel
Warning! DMX control is disabled when the control menus are active. Be
prepared for the head to illuminate as soon as you exit the control menus.
The control panel and backlit graphic LCD display allow you to setup the options for the
xture.
Default information screen
When power is applied, the xture performs a reset. After the reset has completed, the
default information screen appears in the control panel display on the base of the
xture.
At any other time, you can press any key to unlock the control panel. Doing this also
calls up the default information screen in the control panel display.
See Figure 4. The top line of the default information screen consists of, from left to right:
● Main CPU rmware version
● DMX Mode
The center of the screen shows the following information:
● Signal source.
● Fixture’s current DMX address in large characters. If the xture’s self-diagnosis
system detects an error, the xture will ash an error message alternately with the
0.1.2/M1
DMX
001
(1…4)
Figure 4. Default information screen
