German Light Products GLP MAD MAXX
Rev. 20250625-1 13
Lifting and moving the fixture
To lift the fixture:
1. Obtain two chains or cables and shackles that can safely support the weight of
the fixture.
2. Attach the chains or cables to the fixture using shackles passed through the
25 mm diameter eyelets provided in the yoke (see Fixture overview on page 15 –
two pairs of eyelets are provided, one pair at the ends of the yoke and one pair
close to the base of the yoke).
Important! There must be minimum 400 mm /
16 inches of chain or cable between the lifting bar or
lifting equipment and the eyelets in the yoke, no
matter which pair of eyelets you use.
3. Lift the fixture using lifting equipment. Do not try to
lift the fixture manually. Apply the pan and tilt locks
as soon as possible to avoid head movement that
can destablize the fixture.
Warning! See Figure 1. When lifting the fixture, chains or cables must
be attached to at least TWO points as shown at A and B. Do NOT try
to lift the fixture using cables or chains that are attached to one point
only as shown at C.
Warning! The four pillars at the corners of the fixture’s base are
provided to let installers guide the fixture when the fixture’s weight is
already supported. They are not designed to support the weight of
the fixture. Do NOT use them as handles to lift the fixture.
A
B
A
B
C
Figure 1. Lifting the fixture to move it
Min.
400 mm
