German Light Products®
JDC1 User Manual Rev. 20240830-01 13
The following DMX modes are available:
• DMX Mode 1 (Compressed Pro) uses 14 DMX channels. It gives the following control
options that are used as standard in all DMX modes:
- 16-bit control of tilt, allowing the head to be tilted through 185°, using channels 1
and 2.
- Beam shutter effects (strobe, ramp up/down etc.) with variable intensity, duration
and rate using channels 3-6.
- Adjustment of a range of fixture settings from the DMX controller using the Special /
Control commands on channel 7.
- Plate shutter effects (strobe, ramp up/down etc.) with variable intensity, duration
and rate using channels 8-11.
- RGB color mixing on the Plates using channels 12-14.
• DMX Mode 2 (Normal) uses 23 DMX channels. It gives the following control options:
- Standard control options on DMX channels 1-14.
- Pre-programmed dynamic FX patterns on the Beam and the Plates, with
adjustment of FX speed and of crossfades between the FX and the background
using channels 15-19.
- Master intensity and RGB color mixing on the Plates using channels 20-23.
• DMX Mode 3 (SPix) uses 68 DMX channels. It gives the following control options:
- Standard control options on DMX channels 1-14.
- Pre-programmed FX patterns using channels 15-19.
- Master intensity and pixel-level RGB color mixing of Plate pixels 1-12 using channels
20-56.
- Pixel-level white intensity control of Beam pixels 1-12 using channels 57-68.
For pixel layout in the JDC1, see Figure 4 on page 14.
• DMX Mode 4 (SPix Pro) uses 62 DMX channels. It gives the following control options:
- Standard control options on DMX channels 1-14.
- Pixel-level RGB color mixing of Plate pixels 1-12 using channels 15-50.
- Pixel-level white intensity of Beam pixels 1-12 using channels 51-62.
• DMX Mode 5 (1Pix Pro) uses 17 DMX channels. It gives the following control options:
- Standard control options on DMX channels 1-14.
- Grouped RGB color mixing of the Plates using channels 15-17.
• DMX Mode 6 (Easy) uses 11 DMX channels. It gives the following control options:
- Standard control options without Plate shutter effects on DMX channels 1-7.
- Grouped RGBW color mixing of the Plates using channels 8-11.
