German Light Products®
JDC Line 1000 User Manual 7
3. Features
The JDC Line 1000 from GLP® is a powerful LED-based strobe/color effect linear lighting
fixture. It combines a powerful strobe line with RGB and white pixel mapping in one
device.
The JDC Line1000 is twice the length and has twice the performance of GLP’s JDC Line
500. The JDC Line1000 has the advantage that it only requires one power connection,
one data connection and one control panel to run 1000 mm of JDC Line pixels.
Internally, the JDC Line 1000 has two separate strobe and effect engines, which lets
you operate it as if it was two separate 500 mm fixtures.
The DMX channel layout of the JDC Line1000 is based on the layout of 2 x JDC Line
500s. This means that you can simply patch two JDC Line 500s next to each other to
control one JDC Line 1000. The Control / Settings channel of the second patched
fixture is ignored – the JDC Line 1000 uses the Control / Settings channel of the first
patched fixture only.
It features:
● Two sections, A and B, that can be controlled as if they were two JDC Line 500
fixtures.
● Easy integration with the JDC Line 500: one JDC Line 1000 fixture maps onto two JDC
Line 500 fixtures in an existing DMX control setup.
● 2 x 20 super-bright White 25 mm strobe segments
● 2 x 40 super-bright 25 mm RGB segments
● RGB segments can be split into two (80 segments total) for even more zig-zag
effects
● White, RGBW and RGB strobes
● White and RGB pixel mapping, White strobe over RGB pixel mapping, and RGB
strobe over White pixel mapping
● RGBW background channels with separate dimmer for continuous ambient light
● Powerful FX engines with a range of pre-programmed pixel patterns
● Interlocking design that allows almost gapless installation of multiple fixtures
● Rear airflow design that lets you stack fixtures on top of each other or place them
directly on the ground
● Ease of installation with smart, flexible rigging and mounting options
● Control panel with new backlit multicolor LED display
● Quarter-turn locking points for omega clamps and end-to-end fastener bars
The JDC Line 1000 features a central tube of 200 x powerful White LEDs in 40 segments
across its Sections A and B. The white LEDs provide impressive strobe effects and pixel
mapping. Above and below the White LEDs are 400 x RGB LEDs in two rows that can
be controlled as 20, 40, 60 or 80 segments. The RGB LEDs also provide strobe effects
and pixel mapping.
A range of pre-programmed dynamic FX patterns with variable parameters can be
selected and run on the White and RGB segments.
