German Light Products
®
Rev. 20240618-01 31
are mixed using Background color on
DMX channel 6, the Control/Settings
channel. The setting selected on the
Control / Settings channel applies to
both Strobe A and Strobe B.
White segments individual control
adjusts the output of the individual
White segments on each Strobe. The
overall output of these segments is
determined by the White segments
overall control channels (see above)
for each Strobe.
Control / Settings lets you configure the
fixture remotely via DMX. Settings that
you configure on the Control / Settings
channel apply to both Strobe A and
Strobe B.
Strobe B White segments overall control
48
Intensity coarse
49
Intensity fine
50
Duration
51
Flash rate (Shutter)
52
Intensity effects (Strobe mode)
53
No function
Strobe B RGB strobe with FX
54
Intensity coarse
55
Intensity fine
56
Duration
57
Flash rate (Shutter)
58
Intensity effects (Strobe mode)
59
CTC
60
Red
61
Green
62
Blue
63
Pattern select
64
Pattern step / speed
65
Pattern step crossfade
66
Pattern transition
67
Pattern chain length
68
Position in chain
69
Strobe phase
Strobe B Background color
70
Intensity background
71
Red background
72
Green background
73
Blue background
74
White background
Strobe B White segments individual
control
75
White segment 01
…
…
94
White segment 20
