German Light Products
®
Rev. 20240618-01 25
7. DMX control modes overview
The following DMX control modes are available in the JDC Line 1000.
DMX Mode 1: RGBW Strobe
32 DMX Channels
RGBW strobe is a global strobe that
uses all the White and all the RGB
segments on Section A and on Section
B together. This global strobe runs
independently on each Strobe section.
Each strobe has flash, pulse and ramp-
up/down effects as well as special
intensity effects such as lightning. The
strobes offer RGBW control plus
separate color temperature control
that defines each section’s white point.
Background color sets a background
color on the RGB segments for Section
A and B independently. As standard,
the main color output always has
higher priority than the background
color.
You can define how background color
and main color are mixed on both
Strobes using Background color on the
Control/Settings channel.
Control / Settings lets you configure the
fixture remotely via DMX. Settings that
you configure on the Control / Settings
channel apply to both Strobe A and
Strobe B.
Mode 1
RGBW Strobe
Strobe A RGBW
1
Intensity coarse
2
Intensity fine
3
Duration
4
Flash rate (Shutter)
5
Intensity effects (Strobe mode)
6
Control / Settings
7
CTC
8
Red
9
Green
10
Blue
11
White
Strobe A Background color
12
Intensity background
13
Red background
14
Green background
15
Blue background
16
White background
Strobe B RGBW
17
Intensity coarse
18
Intensity fine
19
Duration
20
Flash rate (Shutter)
21
Intensity effects (Strobe mode)
22
No function
23
CTC
24
Red
25
Green
26
Blue
27
White
Strobe B Background color
28
Intensity background
29
Red background
30
Green background
31
Blue background
32
White background
