German Light Products®
Rev. 20240207-01 9
In nearly all DMX modes, the Main module gives color mixing control of all pixels
together as one segment.
● Mode 1 (Basic) gives control of all the fixture’s main functions, with color mixing
control of all nineteen pixels together as one segment.
● Mode 2 (Normal) adds a Sub module as a second layer with pattern effects and
color mixing control of all nineteen pixels together as one segment.
● Mode 3 (Segment) adds Sub module(s) as a second layer with pattern effects and
color mixing of three segments: the inner, middle and outer rings.
● Mode 4 (Multipixel Advanced) adds Sub module(s) as a second layer with pattern
effects and RGB color mixing of each individual pixel.
● Mode 5 (Multipix Compressed RGB) is a pixel mapping mode which offers the main
overall control options plus RGB color mixing of each individual pixel.
● Mode 6 (Multipix Compressed RGBL) is a pixel mapping mode which offers the
main overall control options plus RGBL color mixing of each individual pixel.
Color mixing
The fixture’s Main module features 16-bit color mixing with RGB, RGBL or x;y (CIE 1931)
Color Mix control options. See ‘Color Mix modes’ on page 15.
Note: The Color Mix mode of the Sub module(s) is always RGB. For more details, see
‘Color Mix modes’ on page 15.
iQ.Gamut
iQ.Gamut is a new LED calibration technology from GLP that defines the color gamut
for the color mix channels. You can select one of a range of calibrated iQ.Gamuts for
the fixture to work within. This feature can be useful if you want to reproduce correct
colors or avoid TV camera clipping. See ‘iQ.Gamut’ on page 17.
Mix Priority
The Mix Priority channel defines how the color mixing output of the Main module (Layer
1) and the color mixing output of the Sub module(s) (Layer 2) are merged together – or
which value has higher priority. This lets you switch between the layers or create
special effects using both layers.
The Mix Priority channel gives the following options:
● Main + Sub (HTP) – The fixture takes whichever color value of the Main module or
Sub module is highest and uses that value to determine the output color (Highest
Takes Priority).
● Main Only – The Sub module color value is ignored. The fixture uses the color value
of the Main module.
● Sub Only – The Main module color value is ignored. The fixture uses the color value
of the Sub module.
● Main + Sub additive – The Sub module color value is added to the Main module
color value. The fixture uses the sum of both values.
