www.glp.de    X5 IP
8  impression X5 IP User Manual
position. If it cannot move to this position, it waits for a short period and then tries
again. Position feedback is automatically disabled for a short time if you press one
of the control panel buttons on the yoke. This feature lets an operator move the
yoke manually for more convenient use of the control panel and display. Pan and
tilt remain automatically disabled while you are using the fixture’s control panel.
Position feedback can also be set to constantly disabled using the Fixture Settings
→ Position Feedback setting (see Pan/Tilt disable’ on page 22 or via DMX on the
Special/Control channel.
Fixture performance and speed options
You can adjust the speed (and noise level) of pan and tilt movement, as well as the
speed of all other mechanical effects, by selecting from three different performance
options (see ‘Performance modes’ on page 20).
Zoom
The impression X5 IP has motorized zoom control. Control on the Zoom DMX
channel moves from spot to flood as the DMX value increases.
You can adjust the speed (and noise level) of zoom movement, as well as the speed
of all other mechanical effects, by selecting from three different performance
options (see ‘Performance modes’ on page 20).
Main and Sub module
Some DMX control modes divide the fixture into two or more modules or layers
(Main module and Sub module). For example, DMX modes 2-4 divide the fixture
into:
●  Main module (Layer 1 = one RGB(L) Wash fixture)
●  Sub module (Layer 2 = pattern engine with segment or individual pixel control).
The Sub module has its own intensity and shutter channels. Professional controllers
will handle this setup in a smart multi-fixture profile.
The Sub module mode setting lets you decide whether the Sub module should be
subordinate to or independent of the Main module (see ‘Sub module mode / Sub
fixture mode’ on page 19).
Individual segment or pixel control
The impression  X5 IP has 19 individually controllable pixels. Each pixel cell houses a
40 W RGBL LED that can be controlled individually in intensity and color to create
dynamic effects and pixel mapping.
The fixture’s different DMX control modes offer different options for working with
the individual segments or pixels.
In nearly all DMX modes, the Main module gives color mixing control of all pixels
together as one segment.
●  Mode 1 (Basic) gives control of all the fixture’s main functions, with color mixing
control of all the fixture’s pixels together as one segment.
