www.glp.de X5 IP
22 impression X5 IP User Manual
● Capture DMX Values takes a snapshot of the DMX values that are currently
being received and stores them in the fixture’s memory as its captured scene.
The fixture will display this scene if it is set to Scene (Stand-alone) (see above)
and is not receiving a DMX signal.
Pan invert
With the fixture standing on the ground, increasing the pan DMX value normally
moves the yoke clockwise from its home position.
Changing the Pan invert setting to ON inverts the pan direction so that increasing
the pan value turns the yoke counterclockwise.
Tilt invert
With the fixture standing on the ground, increasing the tilt DMX value moves the
head towards the front from its home position.
Changing the Tilt invert setting to ON inverts the tilt direction so that increasing the
tilt value turns the head towards the back (towards the gray safety eyelet).
Position feedback
Pan and tilt auto-correction (position feedback) is normally enabled (On). Changing
this setting to OFF will disable the position feedback and auto-correction. If you
need to return pan and tilt to their correct positions, you must perform a reset.
Pan/Tilt disable
Changing the Pan/Tilt disable setting to "Current disable" de-activates pan and tilt
by disabling the pan and tilt motor current.
Note: When changing from ON back to OFF to re-enable pan and tilt movement,
you must carry out a reset before you can operate pan and tilt normally.
Pan Range
For normal use and to make swapping fixtures easier, pan is normally limited to a
standard 540° maximum pan angle (NORMAL). However, if you wish to use the full
pan range between mechanical end positions, it is possible to extend the standard
range to the mechanical maximum (EXTENDED).
For details of pan angles, see the technical specifications in the impression X5 IP
Quick Start and Safety Manual supplied with the fixture and available for download
from www.glp.de.
Display Mode
Gives different display behavior options. This can be helpful in case of errors or
during service operations. Three settings are available:
● Auto (default): the display automatically switches off after a few seconds if the
fixture is receiving a valid control signal and has not detected an error. If the
fixture is not receiving a valid control signal, the display will flash. If the fixture
has detected an error, the display remains constantly on and shows the error.
