German Light Products® X5 IP Bar 1000

Rev. 20240207-01 25

● Job Offset: Lets you set +/- offsets on mechanical effects. Custom job offsets let you

adjust fixtures in multiple installations (to compensate for the different positions of

fixtures in a rig, for example).

Any custom job offsets that you create here will not affect the fixture’s effect

calibration.

All custom job offsets created here are deleted if you apply a Load Factory

Defaults command.

● Reset Counters: Resets the different resettable fixture counters.

Device counters are not reset by a Load Factory Backup command.

● Save Settings: Lets you save the current fixture settings to one of the three user

settings presets. You can load a user settings preset that you have saved with a

Load User Settings command (see Fixture Settings → Load User Settings). The default

fixture preset cannot be changed.

This command only saves fixture settings (Fan Mode, Color Mix etc.). It does not

save fixture configuration information such as DMX address and DMX mode.

● Firmware Push (Fixture2Fixture): Pushes the fixture’s firmware (flash storage) to all

other fixtures of the same type via the DMX link.

Important! The impression X5 IP Bar 1000 series firmware is fully compatible with all

impression X5 series fixtures. This means that a firmware push carried out by an

impression X5 IP Bar 1000 will also push its firmware to other impression X5 fixtures

such as impression X5, impression X5 Compact, impression X5 Bar 1000 etc.

Load Factory Defaults

Reloads all factory defaults over the entire fixture and brings the fixture into standard

show condition.

You must confirm the function for 3 seconds before the default settings are loaded.

Important! The factory default settings that are reloaded with this command include all

data and network configuration parameters such as DMX start address, IP

configuration etc. You may therefore lose communication with your controller.

The Load Factory Defaults command does not affect device counters and calibration.

Factory Menu

Important! Do not enter the Factory Menu if you are not a trained service professional

with service documentation or clear instructions from GLP Service. Read the user and

service documentation carefully before entering this menu. In the Factory Menu you

can apply critical settings which can damage the fixture.

The Factory Menu is a hidden menu for the manufacturer or professional service

technicians only. This special menu allows fixture calibration and the adjustment of all

mechanical features following the manufacturer’s instructions.

To enable the Factory Menu, apply power to the fixture and press the ENTER and BACK

buttons together while the pre-boot screen is being displayed. You can release the

buttons as soon as FACTORY MODE appears in the black display. After doing this,
