14 GLP impression S350 Wash User Manual Rev. C
To use framing, select either PI mode (this mode is selected by default) or LR mode
using either the fixture’s control panel or the Special/Control DMX channel. Then use
DMX channels 25 – 32 to control the four framing blades and use DMX channel 24 to
set the indexed angle of the entire framing module.
Iris
The iris gives you continuously variable control of the diameter of the beam.
Shutter effects
The fixture features an electronic dimmer / shutter system that provides pulse and
strobe effects as well as instant open and blackout.
Dimming
0 – 100% continuous dimming is available.
See Figure 4. You can select from two dimming curves using the control panel or the
Special/Control DMX channel: Linear and Extra soft:
• Light output using the Linear curve will appear to increase and decrease evenly
throughout the dimming range.
• The Extra soft curve gives finer control at low light levels (where the eye is more
sensitive to changes in light level) and coarser control at high levels.
The default setting is Extra soft.
Light
output
DMX control value
Figure 4. Dimming curves
Zoom
The impression S350 Wash has a 1:5 zoom range. You can narrow the beam angle from
45° to 6° half-peak / narrow the field angle from 60° to 12° one-tenth peak.
Control on the Zoom DMX channel can be inverted. Normal control as the DMX value
increases is flood
spot. You can invert this using the control panel and the
Special/Control DMX channel so that control becomes spot
flood.
