German Light Products®
GLP impression S350 Wash User Manual Rev. C 13
Color
The S350 Wash features 0-100% continuous CMY color mixing and a 10-slot color wheel
with ten dichroic color filters including CTC (see Figure 3).
A good method of controlling color is to set CMY levels to 0% when you begin to use
the color wheel. Then, after you have selected a color on the color wheel, you can
fine tune it using the CMY channels.
Open Slot 1
Congo Blue
Slot 2
Green
Slot 3
Orange
Slot 4
Magenta
Slot 5
Blue
Slot 6
CTC 1
Slot 7
CTC 2
Slot 8
CTC 3
Slot 9
Minus green
Slot 10
Red
Figure 3. Color wheel
CTC
The CTC DMX channel lets you adjust color temperature from 8 000 K to 2500 K by
deploying the CMY flags. The channel sets the flags into the perfect positions for
matching color temperatures on the black body line.
A recommended approach is to set CMY levels to 0% when you begin to use the CTC
channel. After you have selected a color temperature on the CTC channel you can
fine tune it using the CMY channel.
Framing
The four-blade framing module offers individual control of each blade, and the entire
module can be indexed continuously from -45° to +45°. Blades can be continuously
angled by +/- 30° and inserted by up to 100%, giving flexibility in choice of frame shape
and size right down to dead blackout.
Two framing control modes are available:
• PI (Position/Indexing) mode lets you insert each blade into the beam from 0% to 100%
on one channel and tilt each blade from -30° to + 30° on the next channel. Inserting
all four blades 100% into the beam will result in dead blackout. The fixture is set to PI
mode by default.
• LR (Left/Right) mode gives you individual control of the left-hand and the right-hand
sides of each of the four blades. In this mode, for example, DMX channel 25 gives
control of the left-hand side of blade 1 and channel 26 gives control of the right-hand
side of blade 1.
