www.glp.de DMX control channel layout tables
32 EXO Beam 10 User Manual Rev. A
12. DMX control channel layout tables
DMX Mode 1: Standard
11 DMX Channels
Channel Command
DMX
range Percent
Default
DMX Fade
1 Pan
2 Pan fine
Pan left–right 0 65535
0 100 32767 Fade
3 Tilt
4 Tilt fine
Tilt up–down 0 65535
0 100 32767 Fade
Color 01 – Open
0 3
0.0
1.2
Snap
Color 02 – Primary Red 4 7 1.6 2.7 Snap
Color 03 – Blue 8 11 3.1 4.3 Snap
Color 04 – Primary Green 12 15 4.7 5.9 Snap
Color 05 – Amber 16 19 6.3 7.5 Snap
Color 06 – Cyan 20 23 7.8 9.0 Snap
Color 07 – Magenta 24 27 9.4 10.6 Snap
Color 08 – Cool white 28 31 11.0 12.2 Snap
Color 09 – CTO 3200K 32 35 12.5 13.7 Snap
Color 10 – CTC 6000K 36 39 14.1 15.3 Snap
Color 11 – Pink
40 43
15.7
16.9
Snap
Color 12 – Fern green 44 47 17.3 18.4 Snap
Color 13 – Yellow 48 51 18.8 20.0 Snap
Color 14 - Orange 52 55 20.4 21.6 Snap
Color 15 – Dark blue 56 59 22.0 23.1 Snap
Variable position 0-360°, split colors 60 167 23.5 65.5 Fade
Rotation clockwise fast > slow 168 211 65.9 82.7 Fade
Rotation stop 212 212 83.1 83.1 Fade
5 Color wheel
Rotation counterclockwise slow >
fast
213 255 83.5 100
0
Fade
Open 0 2 0.0 0.8 Snap
Gobo 1 indexed 3 5 1.2 2.0 Snap
Gobo 2 6 8 2.4 3.1 Snap
Gobo 3 indexed 9 11 3.5 4.3 Snap
Gobo 4 12 14 4.7 5.5 Snap
Gobo 5 indexed 15 17 5.9 6.7 Snap
Gobo 6 18 20 7.1 7.8 Snap
Gobo 7 indexed 21 23 8.2 9.0 Snap
Gobo 8 24 26 9.4 10.2 Snap
Gobo 9 indexed 27 29 10.6 11.4 Snap
Gobo 10 30 32 11.8 12.5 Snap
Gobo 11 indexed 33 35 12.9 13.7 Snap
Gobo 12 36 38 14.1 14.9 Snap
Gobo 13 indexed 39 41 15.3 16.1 Snap
Gobo 14 42 44 16.5 17.3 Snap
Gobo 1 rotate 45 47 17.6 18.4 Snap
Gobo 3 rotate 48 50 18.8 19.6 Snap
Gobo 5 rotate 51 53 20.0 20.8 Snap
Gobo 7 rotate 54 56 21.2 22.0 Snap
Gobo 9 rotate 57 59 22.4 23.1 Snap
Gobo 11 rotate 60 62 23.5 24.3 Snap
Gobo 13 rotate 63 65 24.7 25.5 Snap
Gobo 1 shake and index 66 72 25.9 28.2 Snap
Gobo 2 shake 73 79 28.6 31.0 Snap
Gobo 3 shake and index 80 86 31.4 33.7 Snap
6 Gobo wheel
Gobo 4 shake 87 93 34.1 36.5
0
Snap
