INSTALL INSTRUCTION INSTALL INSTRUCTION
INSTALL INSTRUCTION
Remove the exterior and interior packing, wipe the
outside thoroughly with a soft dry cloth and the
inside with a wet, lukewarm cloth.
Avoid placing the cabinet in a narrow recess or
near any heat source, direct sunlight, or moisture.
Let air circulate freely around the cabinet. When
installing the unit, ensure that 10 cm of free space
is left at both sides, 10 cm at the rear of the unit
and 10 cm at the top of the unit.
Before connecting your refrigerator to
the power supply, check that the voltage stated on
the rating label of your appliance corresponds to
the voltage in your home. A different voltage could
damage the appliance.
The appliance must be grounded. The manufacturer
is not responsible for damages that may occur as a
result of usage without grounding.
After installing the product, please let it stay for
more than 2 hours before turning on the power,
otherwise it will lead to a decrease in cooling
capacity or a damage to the product.
List of tools to be provided by the user :
If you have any doubts regarding installation, please
turn to the vendor, to our customer service or to the
nearest Authorised Service Centre.
1 . Power off the refrigerator, and remove all
objects from the door trays.
3. Dismantle the door and the bottom hinge
assembly and adjustable foot, then assemble
the bottom hinge assembly and adjustable
foot on other side.
4. Put the door on bottom hinge and assemble
the upper hinge, screws, and upper cover.
2 . Dismantle the upper cover, fitting screws
of upper hinge, and remove the upper hinge,
please keep the door vertical in whole process
for avoiding falling down.
Allow the appliance to run empty for 24h so the
compartment can cool to the appropriate temperature.
Cross screwdriver
Masking tape
5/16” socket spanner
Putty knife / Thin-
blade screwdriver
Space requirement diagram
STEP
Connecting the applianceBefore the first use
CLIMATE CLASS AMBIENT TEMPERATURE
SN +10 °C TO +32 °C
+16 °C TO +32 °C
+16 °C TO +38 °C
+16 °C TO +43 °C
N
ST
T
135 °
A
B B
C
D
E
553 845 574 935 960
A B
D
EC
2 h
Ambient Temperature
Depending on the climate class, this refrigerator
is intended to be used at an ambient temperature
range as specified in the following table.
The product may not operate properly at
temperatures outside of the specific range. You
can find the climate class on the product label.
The refrigerator should always be plugged into
its own individual electrical outlet which has a
voltage rating that matches the rating plate. When
positioning the appliance, ensure the supply cord
is not trapped ordamaged.
CAUTION
ATTENTION
ATTENTION
Door Right-Left change
The cooling performance and power consumption
of the refrigerator may be affected by the ambient
temperature, the door-opening frequency, and
the location of the refrigerator. We recommend
adjusting the temperature settings as appropriate.
Differences: Due to technical changes and
different models, some of the illustrations in this
manual may differ from your model.
Upper hinge
Fitting screw
Adjustable foot
Bottom hinge
assembly
