18
DOOR ADJUSTMENT
Adjusting the Door (if required)
Adjusting the door front to back (if required)
Rear screw adjusts
door front to back.
Top view of cabinet
Level Not Level
Top view of cabinet
■ Screw the inner screw on the soft closed hinge to adjust the
gap between the doors and shell. Ensure the door is always
level.
Adjusting the door side to side (if required)
Front screw adjusts
door side to side.
Top view of cabinet
■ Screw the outer screw on the soft closed hinge to adjust the
gap between the doors. Ensure the door is always level.
DRAWER REMOVAL AND REPLACEMENT
Drawer removal and replacement
Drawer removal and replacement
Push down – one side
Pull up – other side
■ DRAWER REMOVAL
Empty the drawer. Pull the drawer out so it’s almost fully
extended. There are two black release levers, one on each
side of the drawer. Pull up the black release lever on one side,
while pushing down the black release lever on the other side.
While holding the levers in the positions as instructed above,
pull the drawer outward until it is released from the drawer
slides.
■ DRAWER REPLACEMENT
Extend the drawer slides from the cabinet. Insert the brackets
on each side of the drawer into the slots in the slides, being
careful that they are properly positioned. Once properly
inserted, completely close the drawer to set the slides in their
proper positions.
