45
Model: GVHC & FTroubleshooting
Problem Probable Cause Corrective Action
Underhood Appliance will not power
up:
• [HOOD POWERED] light ON
• [CHARCOAL OR BAFFLE
FILTER
MISSING] light ON
• [
APPLIANCE POWERED] light OFF
a. Baffle Filter missing or not
properly installed
Install Baffle Filter / check alignment.
b. Charcoal Filter missing or not
properly installed
Install Charcoal Filter / check
alignment.
c. One or both Filter switches are
faulty
Test & replace as needed.
Underhood Appliance will not power
up:
• [HOOD POWERED] light ON
• [CHARCOAL OR BAFFLE
FILTER
CLOGGED] light ON
• [
APPLIANCE POWERED] light OFF
• Continuous tone alarm sounding.
a. Baffle or Charcoal Filter clogged
Replace Charcoal Filter or clean Baffle
Filter.
b. Hood exhaust outlet excessively
block
Confirm exhaust is clear of any
obstruction around diverter.
c. Vacuum Switch (clogged filter
sensor) is out of adjustment
Test & adjust vacuum switch.
d. Kinked or blocked vacuum line
Remove vacuum line kinks or
blockage.
e. Fan running slow or blades are
loaded with grease film
Check voltage and inspect blower,
clean if needed
Underhood Appliance will not power
up:
• [HOOD POWERED] light ON
• [
WASH] light ON
• [APPLIANCE POWERED] light OFF
• Intermittent tone (beeping) alarm
sounding.
a. Excessive film built up on
collector fins; too dirty
Clean the EAC cell, Section 4.03.2.
b. EAC cell is not installed Install clean EAC cell.
c. EAC driver board is faulty Test & replace EAC power supply if
d. Poor connection at contact
plate, dirty contacts, cell mis
aligned, faulty contacts.
Check cell position, clean contacts,
inspect contact plate & replace if
needed.
Underhood Appliance operates:
• [HOOD POWERED] light ON
• [CHECK
] light ON
• [APPLIANCE POWERED] light ON
• No alarm sounding, although cell is
NOT cleaning air.
a. Ionizer wire broken & touching
chassis.
Replace ionizer wire.
b. Collector fins shorted to ground
by moisture.
Dry cell, determine cause of
moisture, cool air being drawn into
hood creating condensation.
Underhood lighting does not come on
when Power Switch is ON.
a. Fluorescent bulb burned out Replace bulb.
b. Ballast is faulty Replace ballast.
c. Fuse is blown Check and replace fuse.
6.01 Procedures ‐ continued
