44
Model: GVHC & F Troubleshooting
Problem Probable Cause Corrective Action
Hood will not turn ON
a. Filter Access Door not closed Close & latch Access Door.
b. Improper startup method
Press & momentarily hold in top
[START] portion of power switch.
c. Power Switch is faulty Replace Power Switch.
c. Improper supply voltage Connect to proper electrical supply.
e. Not properly connected to
power source.
Confirm connections & correct.
f. Blown fuse or tripped circuit
breaker.
Check fuse in hood and main breaker
box.
[CHARCOAL OR BAFFLE FILTER
MISSING] light ON at startup
a. Baffle or Charcoal Filter is not
installed or not properly seated
Install appropriate Filter and/or check
alignment in track.
EAC [WASH] light ON & intermittent
(beeping) alarm sounding
a. Excessive film buildup on fins Clean the EAC cell, Section 4.03.2
b. EAC cell is not installed Install EAC Cell
c. Poor connection at contact plate
inside hood.
Check cell position, clean contacts.
d. Faulty EAC contact plate
Have plate inspected, replace if
needed.
EAC [CHECK] light ON; no alarm
sounding
a. EAC shorted to ground (damaged) Replace or repair the EAC cell.
b. High voltage wires shorted to
ground.
Correct shorted condition.
c. Collector fins shorted out due to
excessive moisture.
Eliminate condensation causes cold
air being drawn into hood, etc.
6. Troubleshooting
This section describes basic troubleshooting procedures for model GVH Recirculating Hoods. Generally,
troubleshooting and/or repairs should only be performed by trained and qualified service technicians.
Troubleshooting by users should be limited to issues and/or activities that are operational or procedural in nature.
•
T
roubleshooting for electrical problems should be performed ONLY by trained qualified service technicians or
electricians. Serious injury, or even death, will result from contact with energized electrical circuits.
•
Failure to comply with DANGER notices will result in death or serious injury, equipment or property damage,
and void the warranty.
6.01 Procedures
