17
Installation
GGF Series Gas Fryer
2.12.1 Power Test
1. Confirm that circuit breakers supplying power are ON & fryer power cord is plugged into wall receptacle.
2. Place POWER switch in [ON] position. Green POWER light turns ON & the computer controller powers up.
When alarm sounds after powerup & “POWER FAILURE” message appears on upper controller display ... press
[ALARM] key to silence ... leave POWER switch [ON] and proceed to Section 2.12.2.
If the POWER light does not turn ON and/or controller does not powerup, refer to Section 7.01,
Troubleshooting Procedures.
This test confirms that the unit is receiving power properly.
POWERALARM
1. Be sure that main gas supply line valve is OPEN & that fryer gas valve handle is in the [ON]
position.
2. Heat exchanger ring inside pot should be at room temperature. Wipe the ring with a
soaked wet sponge, leaving visible moisture on its surface.
3. Place SELECTOR switch in the [COOK] position ... the draft fan should start & you should
hear the ignitor sparking ... burners should light momentarily.
NOTE: If burner does not ignite within an allowed time, fryer will enter FLAME FAIL error. Return SELECTOR
switch to [OFF] ... wait 10 seconds & try again.
This test causes the burners to ignite & briefly burn without oil in pot. DO NOT
allow burners to remain ON for
more than 10 seconds
. Failure to observe this precaution may result in damage to the heat exchanger.
2.12.2 Burner Test
DO NOT touch the heat exchanger ring during this test. It becomes very hot ... bare skin contact will result in
severe burn injury.
The following test will verify that gas burner system is receiving fuel & igniting properly.
Continued on Next Page
