6
2.02 Unpacking
IMPORTANT NOTE!!
If the palletized unit had signs of damage, the equipment and all packed accessories should have immediately been
inspected and the freight company promptly notified of the damages. Typically, it is the customer’s responsibility to
negotiate freight damage claims.
•
These hoods are heavy & somewhat topheavy! Exercise due caution when handling to avoid personal injury or
damage to the equipment. Take precautions necessary to avoid damaging the hood stand or legs.
•
Exercise care when removing the protective wooden framework from around the unit to avoid exposed nails or
staples.
• Failure to comply with these CAUTION notices may result in minor to moderate injury, damage to equipment or
property, and void the warranty.
Unit is shipped on a wooden pallet, secured with hightensile plastic strapping & wrapped with machineapplied stretch
film. A wooden crate framework is built around the unit for added protection. Unpack unit as follows:
1. Position the load in an area that provides adequate space for unpacking activities.
2. Remove the plastic stretch wrap, strapping & other packaging materials, as necessary.
3. Carefully remove attached wooden supports and/or crate framework.
4. A carton containing the empty 1‐1/2 gal. wet chemical suppressant tank is generally secured on top of the hood.
Locate this carton & retain for safe keeping ... it will be needed by the Ansul Service Technician when completing field
setup of the fire suppression system.
5. To avoid damage, unit is shipped without the adjustable legs installed. The legs are packaged in a separate carton ...
be sure to secure & retain, see Adjustable Leg Installation below.
6. Carefully remove the unit from the shipping pallet. The hood is very heavy & somewhat topheavy, see Section 1.06,
Unit Weight. Great care should be taken when lifting or moving the unit to avoid personal injury or equipment
damage.
Adjustable Leg Installation
1.
Obtain the adjustable legs.
Model FSH‐2A‐99: Two (2) legs have floor anchor plates & two (2) are standard.
2. With appliance resting on a stable surface, have two helpers tilt the unit forward & hold.
3.
Install the two (2) rear legs
(standard)
into threaded holes on bottom of stand sides, screw in clockwise until
hand tight. Take care not to cross‐thread
... leg should turn fairly easy until tight.
4. Have helpers tilt unit backward onto the installed rear legs, giving access to front of stand. Repeat the process
for two (2) front legs w/foot plates.
Installation Free Standing Ventless Hood
FSH-2 & FSH-2A-99
