* Types of M.2 SSDs supported by each M.2 connector:

M.2 PCIe p26-x4 SSD M.2 PCIe p26-x2 SSD M.2 SATA SSD

M2A_CPU

a a

M2C_CPU

(Note)

a a

M2D_SB

a a

M2B_CPU

(Note)

a a

(Note) Actual support may vary by CPU.

• M2C_CPU/M2B_CPU:

Step 1:

Turn the M.2 EZ-Latch Click clip on the M2D_SB connector clockwise and remove the motherboard

heatsink. Locate the proper mounting hole for the M.2 SSD to be installed and secure the M.2 EZ-Latch

Plus clip in the hole rst.

Step 2:

Insert the M.2 SSD into the M.2 connector at an angle. Press down on the front end of the M.2 SSD

and make sure the M.2 SSD is secured by the clip.

Step 3:

Remove the protective lm from the bottom of the motherboard heatsink, and nally, turn the M.2 EZ-

Latch Click clip clockwise and then install the heatsink back in place.
