- 9 -

Wireless

Communication

Module

 MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0)

- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands

- BLUETOOTH 5.4

- Support for 11be 160MHz wireless standard

 Realtek

Wi-Fi 7 RTL8922AE (PCB rev. 1.1)

- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands

- BLUETOOTH 5.4

- Support for 11be 160MHz wireless standard

(Actual data rate may vary depending on environment and equipment.)

* Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support

driver for Windows 10.)

** Wi-Fi 7 channels on 6 GHz band availability depends on individual country's

regulations.

Expansion Slots  1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:

 AMD Ryzen

™

9000/7000 Series Processors support PCIe 5.0 x16 mode

* The M2B_CPU and M2C_CPU connectors share bandwidth with the PCIEX16 slot.

When the M2B_CPU or M2C_CPU connector is populated, the PCIEX16 slot operates

at up to p9-x8 mode.

 AMD Ryzen

™

8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode

 AMD Ryzen

™

8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode

(The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only

one graphics card is to be installed, be sure to install it in the PCIEX16 slot.)

 Chipset:

- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at p9-x4 (PCIEX4)

* The PCIEX4 slot shares bandwidth with the M2D_SB connector. The PCIEX4 slot

becomes unavailable when a device is installed in the M2D_SB connector.

- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at p9-x2 (PCIEX2)

Storage Interface

 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,

M key, type 25110/22110/2580/2280 SSDs:

 AMD Ryzen

™

9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs

 AMD Ryzen

™

8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs

 AMD Ryzen

™

8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs

 2 x M.2 connectors (M2B_CPU, M2C_CPU), integrated in the CPU, supporting

Socket 3, M key, type 22110/2280 SSDs:

 AMD Ryzen

™

9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs

* The M2B_CPU and M2C_CPU connectors become unavailable when an AMD Ryzen

™

8000 Series-Phoenix 1/Phoenix 2 processor is used.

 1 x M.2 connector (M2D_SB), integrated in the Chipset, supporting Socket 3,

M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs

 4 x SATA 6Gb/s connectors

 RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices

* RAID 5 is only available on AMD Ryzen

™

9000 Series Processors.

 RAID 0, RAID 1, and RAID 10 support for SATA storage devices
