2-2 ProductSpecications

CPU  AMD Socket AM5, support for:

AMD Ryzen

™

9000 Series Processors/

AMD Ryzen

™

8000 Series Processors/

AMD Ryzen

™

7000 Series Processors

(Go to GIGABYTE's website for the latest CPU support list.)

Chipset  AMD X870

Memory  Support for DDR5 5200/4800/4400 MT/s memory modules

 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity)

of system memory

 Dual channel memory architecture

 Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

 Support for AMD EXtended Proles for Overclocking (AMD EXPO

™

) and Extreme

Memory Prole (XMP) memory modules

(The CPU and memory conguration may affect the supported memory types, data

rate (speed), and number of DRAM modules, please refer to "Memory Support

List" on GIGABYTE's website for more information.)

Onboard

Graphics

 Integrated Graphics Processor with AMD Radeon

™

Graphics support+ASMedia

USB4

Controller:

- 2 x USB4

USB Type-C

ports, supporting USB4 and DisplayPort video

outputs and a maximum resolution of 3840x2160@240 Hz

* Support for DisplayPort 1.4 version and HDR.

 Integrated Graphics Processor with AMD Radeon

™

Graphics support:

- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.1 version, HDCP 2.3, and HDR.

** Support native HDMI 2.1 TMDS compatible ports.

- 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz

* Support for HDMI 1.4 version

(Graphics specications may vary depending on CPU support.)

 Support for up to quad-display at the same time

Audio  Realtek

ALC1220 CODEC

* The back panel line out jack supports DSD audio.

 High Denition Audio

 2/4/5.1/7.1-channel

* You can change the functionality of an audio jack using the audio software. To congure

7.1-channel audio, access the audio software for audio settings.

 Support for S/PDIF Out

LAN  Realtek

2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
