16
STEAM&VACUUM TRANSPARENT NOZZLE
Nozzle to be connected directly to the
flexible hose or to the extension
tubes. It can be used only with steam
or with steam, detergent and
vacuum. Suitable for both hard and
soft surfaces (like sofas, carpets,
etc.)
TANK SUCTION ACCESSORY
Accessory to be
connected to the
flexible hose to
vacuum and clean the
tanks.
MICROFIBER CLOTH
Cloth to be used hooked with
the multi-purpose brush to
clean delicate surfaces, such
as wooden floors, furniture,
etc. It offers a great
absorption power, reduces
the power of the steam
dispensed and reduces the friction of the brush
during the treatment
BRUSHES
These
brushes must be
connected to the
STEAM LANCE. They are used to
remove resistant dirt and for deep
cleaning, even in the corners or small
spaces. Choose the most suitable
type (ø28, 40, 60 mm) according to
the surface to be treated.
MANTAINANCE (End user)
* Always remove the plug before cleaning
or carrying out operations on the machine.
* End user must not open or dismantle the
machine.
For the safety of the operator and to always ensure a
perfect performance, we recommend the following
checks and maintenance:
AFTER EVERY USE:
For a correct cleaning, it is advice to clean the machine
and its accessories with a clean cloth moistened only
with a few drops of water. Do not use alcohol or other
solvents, they may damage the plastics and
components.
To maintain efficient and easy to couple the accessories,
check the o-ring seal (steam sealing gaskets) and
possibly wet them with a little silicone grease.
VACUUM FUNCTION: when you finish to vacuum, it is
advisable to vacuum some water to clean the conducts
and the filter. Afterwards, dry the bucket or do not totally
close it so that it will dry itself.
PERIODICALLY:
Periodically check that the power cord does not show
signs of wear or aging. If it is damaged, it is absolutely
necessary to get it replaced by specialized personnel
before being able to re-use the appliance again.
BOILER CLEANING (End user)
Once a year a check and boiler cleaning must be carried
out in our authorized centers.
1-RINSE: It’s recommended at least every 50 hours of
operation or 2 months.
a) DISCHARGE: The machine must be cold or definitely
discharged from the steam pressure and the plug
disconnected. With the help of a wrench CH 21 unscrew
the cap (15) placed under the machine in
correspondence of the boiler (see image). After having
taken off the cap, shake slightly the machine to let the
water and the dissolved limestone out.
When the boiler is empty, clean and close carefully the
cap tightening it with the wrench.
b) FILLING: Fill the water tank (7), turn the machine on
and make it start again, waiting for the boiler to be re-
charged again.
(att: it may be that during the first charge cycle, the “end
of water” light turns on and you need to shut down/restart
the machine to complete the load)
2-BOILER AND TANK CLEANING: "-SEr": The
boiler cleaning advise is shown on the machine display
every 300 litres of water consumed and is repeated
when the machine is started up until the cleaning is
completed and the following Service Reset. However,
cleaning the boiler is recommended at least once every
6 months.
When the -SEr warning appears on the display
accompanied by some audible beeps, this is the
15
