v
Note for People Counting
To use the camera’s built-in people counting feature (see 3.6.1.8 People Counting in the User’s
Manual), which is only supported by certain models, it is recommended to install the camera
according to the criteria listed below:
Surveillance Condition
• The camera shall be installed at a site with uniform, sufficient lighting, where the person(s) to be
counted are fully illuminated.
• The camera shall be installed at an entrance or exit with an ideal width of 1 ~ 4 m (3.28 ~ 13.12 ft),
where the persons(s) to be counted move toward the lens of the camera in single file.
Example of Recommended Scene
Example of Non-recommended Scene
Camera Position
• The camera shall be mounted at a recommended height of 3 ~ 5 m (9.84 ~ 16.4 ft).
• The camera shall be mounted with a recommended depression angle of 70 ~ 80°.
• The camera shall be positioned so that the person(s) to be counted face toward the lens of the
camera and are displayed on the image with a shoulder size of between 120 ~ 160 pixels.
Surveillance
area width
Horizontal line
Depression angle α
Optical axis of
the camera
Pedestrian walking direction
(straight along the center of
the ground)
Horizontal surveillance distance
Device mounting height
