iv
Note for Face Detection
To use the camera’s built-in face detection feature (see 3.6.1.7 Face Detection in the User’s Manual),
which is only supported by certain models, it is recommended to install the camera according to the
criteria listed below
Surveillance Condition
• The camera shall be installed at a site with uniform, sufficient lighting, where the face(s) to be
detected are fully illuminated.
Example of Recommended Scene
Example of Non-recommended Scene
Camera Position
• The camera shall be mounted at a recommended height of 2.5 ~ 3 m (8.2 ~ 9.84 ft).
• The camera shall be mounted with a recommended depression angle of around 10°.
• The camera shall be positioned so that the face(s) to be detected are directly aligned with the
lens of the camera, with a horizontal deviation of no greater than 30°, a vertical deviation of no
greater than 15° and a face size of at least 120 pixels.
Surveillance
area width
Horizontal line
Depression angle α
Optical axis of
the camera
Pedestrian walking direction
(straight along the center of
the ground)
Horizontal surveillance distance
Device mounting height
