page | 15
Advanced Operation
RS-232 and IP Conguration
IP / UDP Conguration
The 4x1 Switcher for HDMI 4K x 2K supports IP-based control using Telnet, UDP, or the
built-in Web-based GUI. To set up IP control, the network settings for the 4x1 Switcher
for HDMI 4K x 2K must be congured via RS-232. The default network settings for the
switcher are as follows:
Description IP Address / Port Description IP Address / Port
IP Address
192.168.1.72
UDP Port
23
Subnet
255.255.255.0
Local UDP Port
50007
Gateway
192.168.1.254
Remote UDP IP
192.168.1.255
HTTP Port
80
Remote UDP Port
50008
1. Connect an RS-232 cable from the PC to the 4x1 Switcher for HDMI 4K x 2K.
Also make sure that an Ethernet cable is connected between the switcher and the
network.
2. Launch a terminal emulation program (e.g. HyperTerminal) and use the RS-232
settings listed on the previous page.
3. Set the IP address for the switcher using the #sipadd command.
4. Set the subnet mask using the #snetmask command.
5. Set the gateway (router) IP address using the #sgateway command.
6. Set the Telnet listening port using the #set_telnet_port command.
7. Set the HTTP listening port using the #set_http_port command.
8. Set the UDP remote IP address for the switcher using the #set_udp_remote_ip
command.
9. Set the UDP listening port for the switcher using the #set_udp_port command.
10. Set the UDP remote port for the switcher using the #set_udp_remote_port
command.
11. Reboot the switcher to apply all changes, then type the IP address that was
specied in step 3, in a Web browser to access the Web GUI. Use the same IP
address to Telnet to the switcher.
NOTE: Depending upon the network, all related IP, Telnet, and
UDP settings will need to be assigned. Consult your network
administrator to obtain the proper settings.
