24
Setting the Channel Using the Front Panel
1. Press the recessed - or + button on the Transmitter to congure the TX Channel. The
TX Channel will be displayed on the front panel display.
2. Press the - or +/USB button on the Receiver to display the current channel number
it is routed to. The routed channel will be displayed on the front-panel display and
onscreen. An OSD Picture-in-Picture (PiP) will also show a preview of the source
being routed to.
The OSD PiP is enabled by factory default. This can be disabled via Receiver
WEBGUI or API command. For more information, refer to the Gen3 API manual.
3. The current video channel of the Receiver unit will be shown on the connected
display as well as on the CH ID display on the front panel.
Source 1
Source 2
Ch=2
4. While the current video channel is being displayed, press and release the Channel
+/- button on the Receiver unit. The Receiver unit will change to the next available
video channel that is being used by a Sender unit. Picture-in-Picture (PiP) source
preview will briey appear onscreen when using the Channel +/- buttons. The
Channel numbers range from 0 to 39900.
Setting the Video Channel
