11
Installation & Conguration
The 4K60 HDMI & USB-C KVM over IP Sender and Receiver units can be connected
over a Local Area Network (LAN) or they can be directly connected to one another. Both
installations will be covered.
Local Area Network (LAN) Connection
In order to connect the 4K60 HDMI & USB-C KVM over IP to a Local Area Network (LAN),
both the Sender and Receiver unit must rst be set to DHCP mode or Static IP mode.
DHCP mode will use the DHCP server to automatically assign an IP address for each
Sender and Receiver unit that is connected to the network. Static IP mode will allow the
IP address for each Sender and Receiver unit to be congured manually. Contact your
network administrator if necessary.
1. Connect a high-quality HDMI or USB-C cable to connect a 4K Ultra HD source to
the HDMI In port or USB-C In port on the rear panel of the Sender (Tx) unit. It is
recommended to use Gefen’s HDMI 2.1 cables to ensure performance.
2. Connect a HDMI cable from the HDMI OUT port on the Sender unit to a local
display.
3. Connect an HDMI cable from the 4K UHD display to the HDMI Out port on the
Receiver unit.
4. Connect a CAT-5e (or better) cable between the LAN1 (PoE) port on the Sender unit
and a Gigabit IP switch.
5. Connect LAN 1 (PoE) on the Receiver unit to the same network switch. Each cable
run can be up to 330 feet (100 meters).
Important: If the IP switch is PoE compliant and the Sender and Receiver are connected
through their PoE ports, external power supplies are not required. Additional Receivers or
other devices connected to LAN 1 and LAN 2 ports of a Receiver will, however, need to be
powered locally.
Installation & Conguration
