RS-232 SERIAL CONTROL COMMANDS
RS-232 Features
RS-232 remote functions are used to control the 16x16 DVI Matrix. Features
include input to output routing, EDID storage, EDID management, etc. These
functions are available only through the use of the serial port.
Functions Syntax
The syntax for each function is always the same:
Character as the start fl ag → Function name → Space ( _ ) as function name end
fl ag → Parameter 1 → Space → Parameter n → Carriage Return ( \r ) →
Sample:
#FunctionName_param1_param2_param3_param4...\r
Syntax is NOT case sensitive.
EDID Management
Function Description
#EDIDDSTOLO Read downstream EDID and stores into a Local EDID
#EDIDDSTOBA Read downstream EDID and stores in EDID Bank
#EDIDBATOLO Read downstream EDID and stores in any Local Input
#PRDSEDID Read downstream EDID and sends to serial port
#PRLOEDID Read Input Local EDID and sends to serial port
#PRBAEDID Read downstream EDID from bank and sends to serial port
#LOEDIDTOLO Load EDID fi le using serial port to one of the local memories
