30
WALL SLEEVE INSTALLATION DATA (CONTINUED)
WALL SECTION – DETAILED SIDE VIEW
Window, 2" curtain or panel wall installation with rag rear grille extended beyond outer wall surface
ROOM
CABINET
Gasket and
caulk around
perimeter of
wall sleeve
all four sides
where it joins
the building
WALL Sleeve
OUTDOOR
GRILLE
Gasket and
caulk around
perimeter of
wall sleeve
all four sides
where it joins
the building
Sleeve ANGLE (FIELD
SUPPLIED)
RAB71B 22-13/16"
RAB78B 22-9/16"
WITH RAG61-63
RAB71B 21-1/16"
RAB78B 21-3/8"
WITH RAG60
16"
RECEPTACLE
(BY OTHERS)
MIN. 2 SUPPORTS
FIELD SUPPLIED
FLOOR
USE NO
SCREWS IN
BOTTOM OF
Sleeve
16"
ROOM
CABINET
WALL Sleeve
OUTDOOR
GRILLE
Sleeve ANGLE (FIELD
SUPPLIED)
RAB71B 22-13/16"
RAB78B 22-9/16"
WITH RAG61-63
RAB71B 21-1/16"
RAB78B 21-3/8"
WITH RAG60
16"
16"
WALL OR
WINDOW
SIDE
CHANNEL
(RAK204)
SUB-BASE
POWER
SUPPLY
CONDUIT
(ALTERNATE ENTRY)
LEVELING LEG
3" MIN.
5" MAX.
FLOOR
SUB-BASE CONNECTEDCORD-SET CONNECTED
GASKET
(FIELD
SUPPLIED)
WALL SLEEVE INSTALLATION DATA (CONTINUED)
