20 1557900 REV B 1 Garrett Metal Detectors

5.6 Detector Settings

Once an access code has been entered, the user may scroll

through the menu items. Depending upon the user’s

access level, some menu items are available as “view only”

and don't show a colon after the function name. Menu

functions that are selectable will have a colon after the

function name. Paragon will not allow a user to change

any of the “view only” items. To scroll down or up through

the menu items, use the MENU



and MENU



key-

pads; or press OPERATE to exit and return to normal

operation.

• Language

LANGUAGE, which indicates the current lan-

guage setting, appears on the Display. If the user is

authorized to change the language setting, the user

may scroll through the language selections using

the + / - keypads. Choose from: English, Spanish,

Turkish, German, Czech, French, Polish, Japanese,

Italian, Portuguese, Russian, or Dutch.

Other languages are available on request.

• User Presets Function

Switching ON this setting allows the Adminis-

trator to dene the critical detection settings (i.e.

Program, Sensitivity, Zone Boosts, and Random

Alarm %) and assign them to three User Presets.

For example:

• User Preset1 = {Program Special Events, Base

Sensitivity 155, Zones 1–22 = 0% boost, Rand

Alarm 0%}

• User Preset2 = {Program Airports, Base

Sensitivity 155, Zones 1–22 = 0% boost, Rand

Alarm 10%}

• User Preset3 = {Program Prisons, Base

Sensitivity 185, Zones 1–22 = 0% boost,

Rand Alarm 0%}

Once dened by the Administrator, the Supervisor

or Administrator can select from the dierent User

Presets to quickly change the detector to the dif-

ferent user-dened security levels (see Section 5.1).

Switch OFF to disable the User Presets setting.

Press the + / - keypads to switch ON/OFF.

Select User Preset

1. Log in as Administrator

2. Press MENU to conrm that Users Presets is

set to ON.

3. Press the MENU



keypad again to see

the current User Preset number (1, 2, or 3).

4. To select a dierent User Preset, press the

(+) or (-) keypads until the desired

User Preset is shown.

5. Once prompted press (+) keypad to conrm

this selection, or press (-) keypad to

cancel.

Modify User Presets (Administrator only)

Any of the three User Presets can be dened or

modied by the Administrator by following these

steps:

1. Select User Preset 1, 2, or 3 using the (+) or

(-) keypads.

2. Once prompted press plus (+) to conrm

selection or minus (-) to cancel.

3. Scroll through the menu items to modify

or dene the following four critical detec-

tion parameters: Program, Base Sensitivity,

Zone Boost, and Random Alarm %. Note

that any detection parameter can be

modied, but only these four parameters

will be permanently retained by the User

Preset that is being modied.

4. Repeat steps 1–3 for remaining User Presets

as needed.

• Multi-Unit Role

is setting is factory preset to SOLO. (Refer to

Section 7 for a more detailed explanation of synchro-

nization.)

SOLO is for a standalone unit and provides

self-generated synchronization based on the FRE-

QUENCY setting with no synchronization avail-

able to adjacent units.

LEADER provides self-generated synchroni-

zation based on the FREQUENCY setting, and,

using am embedded wireless sync module or hard

wires, provides synchronization information to

nearby detectors.

FOLLOWER synchronizes Paragon to a

designated LEADER that is set to the same

FREQUENCY.

• Auto Frequency Scan

Press the (+) button to initiate the unit’s automatic

1 minute frequency scan procedure, which will

select the operating frequency with the least in-

terference from surrounding electrical equipment.

Paragon uses an embedded wireless sync module

Detector Settings
