Viewing Track Details

From the menu page, select TRACKS > LIST SAVED.

Select a track.

Select an option:

• To view the track on the map, select SHOW MAP.

• To view an elevation plot of the track, select ELEVATION.

Editing the Name of a Track

From the menu page, select TRACKS > LIST SAVED.

Select a track.

Select RENAME.

Clearing the Active Track

From the menu page, select TRACKS > CLEAR TRACK >

YES.

Deleting a Track

From the menu page, select TRACKS > LIST SAVED.

Select a track.

Select DELETE > YES.

Deleting All Tracks

From the menu page, select TRACKS > DELETE ALL

SAVED > YES.

Customizing Your Device

Adjusting the Backlight Timeout

You can decrease the backlight timeout to maximize the battery

life.

From the menu page, select SETUP > DISPLAY > LIGHT

TIMEOUT.

Select or to adjust the length of time before the

backlight turns off.

Map Options

From the map page, select ENTER.

PAN TRACK LOG: Allows you to use or to pan the track

log and view additional options (Using the Pan and TracBack

Feature, page 3).

CLEAR TRACK LOG: Deletes the recorded track log.

MEASURE DISTANCE: Allows you to measure the distance

between two waypoints (Measuring the Distance Between

Two Waypoints, page 3).

MAP DETAIL: Sets map preferences (Map Detail Settings,

page 4).

HIDE STATUS INFO: Allows you to hide and show the status

icons on the map page, such as battery level and GPS

status.

Map Detail Settings

From the map page, select ENTER > MAP DETAIL.

MAP ORIENTATION: Adjusts how the map is shown on the

page. The NORTH UP option shows north at the top of the

page. The TRACK UP option shows your current direction of

travel toward the top of the page.

ACTIVE TRACK: Shows or hides the active track on the map.

WAYPOINTS: Shows or hides waypoints on the map.

Compass Options

From the compass page, select ENTER.

CALIBRATE COMPASS: Calibrates the electronic compass

(Calibrating the Compass, page 4).

CHANGE FIELDS: Allows you to customize the data fields on

the compass page (Customizing the Data Fields, page 4).

Calibrating the Compass

The device has a 3-axis electronic compass. You should

calibrate the compass after moving long distances, experiencing

temperature changes, or changing the batteries.

From the compass page, select ENTER > CALIBRATE

COMPASS > START.

Follow the on-screen instructions.

Customizing the Data Fields

You can customize the data fields displayed on the compass,

trip computer, and Applied Ballistics pages.

TIP: You may need to change data fields to view connected

sensor data, such as readings from a heart rate monitor or

tempe sensor.

Select a page with data fields.

Select ENTER > CHANGE FIELDS.

Select the data field to replace.

Select the new data field.

Elevation Options

From the elevation page, select ENTER.

PLOT OVER TIME: Allows you to view elevation changes over a

period of time.

PLOT OVER DIST: Allows you to view elevation changes over a

distance.

ZOOM ELEVATION: Sets the elevation scale.

VIEW POINTS: Enables data points on the elevation page.

Calibrating the Barometric Altimeter

You can manually calibrate the barometric altimeter if you know

the correct elevation or the correct barometric pressure.

Go to a location where the elevation or barometric pressure

is known.

From the menu page, select SETUP > ALTIMETER >

CALIBRATE ALTIMETER.

Follow the on-screen instructions.

Trip Computer Options

From the trip computer page, select ENTER.

CHANGE FIELDS: Allows you to customize the data fields on

the trip computer page (Customizing the Data Fields,

page 4).

RESET TRIP DATA: Resets the trip and elevation data

(Resetting the Trip Computer, page 4).

Resetting the Trip Computer

For accurate information, you can reset the trip and elevation

information before beginning a trip.

From the menu page, select SETUP > RESET > RESET

TRIP DATA > YES.

Applied Ballistics Options

NOTE: This feature is available only on the Foretrex 701 device.

From the Applied Ballistics page, select ENTER.

QUICK EDIT: Allows you to quickly edit the range, direction of

fire, and wind information (Quickly Editing Shooting

Conditions, page 2).

RANGE CARD: Allows you to view elevation and windage for

various ranges based on user input parameters. You can

change fields (Customizing the Range Card Fields,

page 5), edit the range increment (Editing the Range

4 Customizing Your Device
