v Occasionally clean the ventilation slots and the contacts of the battery

with a soft, clean and dry brush.

4.3.2 Cleaning the battery charger

v Clean the contacts and the plastic parts with a soft, dry cloth.

5. STORAGE

5.1 Decommissioning

The product must be stored out of reach of children.

1. Remove the battery.

2. Charge the battery without the battery protective cover

(see 3.1 Charging the battery).

3. Clean the multi-cleaner, the battery and the battery charger

(see 4. MAINTENANCE).

4. Store the multi-cleaner, battery and battery charger in a dry, enclosed

place where they are protected from frost.

5. Do not store the multi-cleaner supported on the brush.

This prevents deformation of the brush.

6. TROUBLESHOOTING

CAUTION! Water damage!

Water damage due to unintentional starting.

v Disconnect the water supply.

v Remove the battery before troubleshooting the product.

6.1 Replacing the brushes

The GARDENA spare parts are available from your GARDENA dealer

or from GARDENA Service.

Only the following 3 GARDENA brushes may be used:

• GARDENA Roller Brush Universal Art. 14848: For cleaning wooden

surfaces. Ideal for decking boards and decks made of wood, soft and

hardwood sections, WPC and BPC. Not suitable for sealed surfaces.

• Gardena Roller Brush Medium Art. 14849: For powerful cleaning.

Ideal for coarse dirt such as moss and green growth. Suitable for stone

surfaces (smooth paving stones, tiles and concrete blocks). Not suita-

ble for sealed surfaces.

• GARDENA Disc Brush Soft Art. 14847: For gentle cleaning. Ideal for

light cleaning work on surfaces. Ideal for cleaning hard-to-reach areas,

corners and edges, steps and plinths.

6.1.1 Replacing the roller brush [Fig. T1]

If the housing of the cordless multi-cleaner touches the ground while

cleaning the ground due to wear, the brush must be replaced.

There are 2 GARDENA roller brushes available:

v Only use an original GARDENA Roller Brush.

1. Turn the fastener

anti-clockwise.

2. Pull off the fastener

3. Pull the roller brush

off the roller brush holder

4. Push the new roller brush

onto the roller brush holder

5. Insert the fastener

into the roller brush

6. Turn the fastener

clockwise as far as it will go until the connection

audibly engages.

This secures the roller brush.

6.1.2 Replacing the disc brush [Fig. T2]

v Only use an original GARDENA Disc Brush.

1. Pull the disc brush

off the disc brush holder

2. Push the new disc brush

onto the disc brush holder

as far as it

will go. This secures the disc brush.

6.2 Error table

2. If necessary, connect the multi-cleaner to the water supply (as described

in 2.4 Connecting the multi-cleaner to the water supply).

3. Pull the protective battery cover

over the battery.

4. Insert the battery

into the battery holder

until it audibly engages.

5. Before you start cleaning: Test the suitability of the brush you intend to

use on some sample material or in an inconspicuous location.

6. Hold the multi-cleaner with one hand on the handle

and the other

hand on the additional handle

7. Pull the start lever

towards the handle

The multi-cleaner starts and the battery state of charge indicator

displayed for 5 seconds.

3.5.2 Stopping the multi-cleaner

1. Release the start lever

The multi-cleaner stops.

2. Press the release button

and remove the battery

from the battery

holder

3.6 Adjusting the water flow [Fig. O7]

Youcanadjustthewaterflowin3steps.

• 0 No water flow

• 1 Reduced water flow

• 2 Full water flow

v Turn the flow control knob

to the desired position.

3.7 Adjusting the brush rotation speed [Fig. O7]

Youcanadjusttherotationspeedofthebrushcontinuouslyfrommin to max.

v Turn the power regulator

to the desired position.

4. MAINTENANCE

CAUTION! Water damage!

Water damage due to unintentional starting.

v Disconnect the water supply.

v Remove the battery before servicing the product.

4.1 Cleaning the multi-cleaner [Fig. M1]

DANGER! Personal injury!

Riskofinjuryandriskofdamagetotheproduct.

v Donotcleantheproductwithwaterorawaterjet(especiallya

high-pressurewaterjet).

v Do not clean with chemicals, including petrol or solvents. Some may

destroy important plastic parts.

The ventilation slots must always be clean.

1. Clean the multi-cleaner with a damp cloth (do not immerse the brush

unit or clean it under running water).

2. Clean the ventilation slots

with a soft brush (do not use a

screwdriver).

3. Clean all moving parts after each use.

4.2 Cleaning the brushes

1. Remove the brushes from the brush unit (see 6.1 Replacing the

brushes).

2. Clean the brushes under running water. Remove particularly small

stones and dirt residues from the brushes.

3. For the roller brush only: Clean the brushes

on the splash guard.

4. Fit the brushes in the brush unit (see 6.1 Replacing the brushes).

4.3 Cleaning the battery and battery charger

The surface and contacts of the battery and the battery charger must be

clean and dry before connecting the battery to the charger.

V Do not use running water.

4.3.1 Cleaning the battery

Do not use any chemical substances to clean the battery.

GAR_14840-20.960.03.indd 12GAR_14840-20.960.03.indd 12 07.02.2024 09:13:4507.02.2024 09:13:45
