77
(Top right corner)
Manual mode
How to select the operating modeHow to select the operating mode
The fish finder is available in automatic and manual operation. For automatic operation, gain, clutter and
TVG are automatically adjusted.
How to change the range
Pinch screen.
How to adjust the gain
How to reduce clutter
Auto
mode
Manual
mode
OR
(Tap [+], [-] icon at left edge
of screen.)
Drag the slider bar
to set the gain.
For dual frequency transducer
Open the Layers
menu, tap the
[Fish Finder] tab.
Open the Layers
menu, tap the
[Fish Finder] tab.
Open the Layers
menu, tap the
[Fish Finder] tab.
Increase
range
Decrease
range
Tap
OFF
Tap
Tap
Tap
The larger the value, the more the clutter is reduced.
Open the Layers
menu, tap the
[Fish Finder] tab.
T
Tap
Tap
Tap
Tap
Drag the slider bar
to set the range.
(Top right corner)
Tap
(Gain can also be
adjusted by tapping the
slider bar or +/- buttons.)
(Range can also be
adjusted by tapping the
slider bar or +/- buttons.)
